C9200L-48PXG-4X-E C9200L 48-p 12xmGig, 36x1G, 4x10G PoE+, Network Essentials Discount
ราคาพิเศษกรุณาขอผ่านทาง[email protected]
Contact
02-026-6862 Head Office
097-318-6865 Mr. Arnon
097-285-3476 Ms. Maneerat
095-467-6396 Ms. Sunanta
081-774-8189 Admin (Sales)
ติดต่อทางLine@: @Quiznet.co.th
หมายเหตุ
1. รูปสินค้าที่แสดงเป็นเพียงรูปภาพประกอบการขายเท่านั้น
2. ทางบริษัทฯ ขอสงวนสิทธิ์ในการเปลี่ยนแปลงราคาและโปรโมชั่นโดยไม่แจ้งให้ทราบล่วงหน้า
3. ทางบริษัทฯ ขอสงวนสิทธิ์ในการรับผิดชอบใดๆ อันเนื่องจากข้อผิดพลาดจากการนำข้อมูลเข้าสู่หน้า Website เช่น รุ่นสินค้า, รายละเอียดสินค้า, รูปภาพสินค้า เป็นต้น
4. เนื่องด้วยสถานการณ์การแพร่ระบาดของ COVID-19 สินค้าบางรายการอาจจะมีการปรับราคาสูงกว่าหน้า Website
Description
C9200L-48PXG-4X-E C9200L 48-p 12xmGig, 36x1G, 4x10G PoE+, Network Essentials
ขอใบเสนอราคา ขาย C9200L-48PXG-4X-E C9200L 48-p 12xmGig, 36x1G, 4x10G PoE+, Network Essentials Discount ราคา ถูก โปรโมชั่นพิเศษ ได้ที่นี้
specification
Table 1 shows the quick spec.
Model | C9200L-48PXG-4X-E |
Downlinks total 10/100/1000 or PoE+ copper ports | 48 ports full POE+ (12 mGig ports up to 10G, 36 ports up to 1G) |
Uplink configuration | 4x 10G fixed uplinks |
Default primary AC power supply | PWR-C5-1KWAC |
Fans | Fixed redundant |
Software | Network Essentials |
Stacking bandwidth | 80 Gbps |
DRAM | 2 GB |
Flash | 4 GB |
Switching capacity | 392 Gbps |
Forwarding rate | 291.66 Mpps |
Chassis Dimensions | 1.73 x 17.5 x 13.8 in
4.4 x 44.5 x 35.0 cm |
Product Details
Catalyst 9200 series provides these highlights:
● Up to 48 ports of full Power over Ethernet Plus (PoE+) capability
● Resiliency with Field-Replaceable Units (FRU) and redundant power supply, fans, and modular uplinks
● Flexible downlink options with data or PoE+
● Operational efficiency with optional backplane stacking, supporting stacking bandwidth up to 160 Gbps
● UADP 2.0 Mini with integrated CPU offers customers optimized scale with better cost structure
● Enhanced security with AES-128 MACsec encryption, policy-based segmentation, and trustworthy systems
● Layer 3 capabilities, including OSPF, EIGRP, ISIS, RIP, and routed access
● Advanced network monitoring using Full Flexible NetFlow
● Cisco Software-Defined Access (SD-Access):
◦ Simplified operations and deployment with policy-based automation from edge to cloud managed with Cisco Identity Services Engine (ISE)
◦ Network assurance and improved resolution time through Cisco DNA Center™
● Plug and Play (PnP) enabled: A simple, secure, unified, and integrated offering to ease new branch or campus device rollouts or updates to an existing network
● Cisco IOS XE: A Common Licensing based operating system for the enterprise Cisco Catalyst 9000 product family with support for model-driven programmability and streaming telemetry
● ASIC with programmable pipeline and micro-engine capabilities, along with template-based, configurable allocation of Layer 2 and Layer 3 forwarding, Access Control Lists (ACLs), and Quality of Service (QoS) entries
Supported Products
Table 2 shows the recommended supported products.
StackWise-80 and StackWise-160 Kit and cables | |
Product number | Product description |
C9200L-STACK-KIT= | C9200L Stack Kit Spare |
STACK-T4-50CM | 50CM Type 3 Stacking Cable |
STACK-T4-1M | 1M Type 3 Stacking Cable |
STACK-T4-3M | 3M Type 3 Stacking Cable |
Soft Licenses | |
Product number | Product description |
C9200L-DNA-P-48 | C9200L DNA Premier Term, 48-Port: Includes Term Licenses for DNA Advantage, 25 ISE Base & 25 ISE Plus Endpoints, 25 Stealthwatch Flows (including Virtual Flow Collector & Management Console). Requires separate purchase of ISE appliance/ISE VM and DNA Center appliance |
C9200L-DNA-P-48-3Y | C9200L DNA Premier, 48-port, 3Y Term – DNA, 25 ISE PLS and ISE BASE, 25 SWATCH |
C9200L-DNA-P-48 -5Y | C9200L DNA Premier, 48-port, 5Y Term – DNA, 25 ISE PLS and ISE BASE, 25 SWATCH |
C9200L-DNA-P-48 -7Y | C9200L DNA Premier, 48-port, 7Y Term – DNA, 25 ISE PLS and ISE BASE, 25 SWATCH |
Power supplies | |
Product Number | Product Description |
PWR-C5-1KWAC/2= | 1000WAC power supply spare |
Compare to Similar Items
Table 3 shows the comparison.
Model | Downlinks | Uplinks | Power Supply | Fans |
C9200L-24PXG-4X-E | 24 ports full PoE+ (8 mGig ports up to 10G, 16 ports up to 1G) | 4x 10G fixed uplinks | PWR-C5-600WAC | Fixed redundant |
C9200L-48PXG-4X-E | 48 ports full POE+ (12 mGig ports up to 10G, 36 ports up to 1G) | 4x 10G fixed uplinks | PWR-C5-1KWAC | Fixed redundant |
C9200L-24PXG-2Y-E | 24 ports full PoE+ (8 mGig ports up to 10G, 16 ports up to 1G) | 2x 25G fixed uplinks | PWR-C5-600WAC | Fixed redundant |
C9200L-48PXG-2Y-E | 48 ports full POE+ (8 mGig ports up to 10G, 40 ports up to 1G) | 2x 25G fixed uplinks | PWR-C5-1KWAC | Fixed redundant |
Warranty
Warranty / เงื่อนไขการรับประกัน: ติดต่อสอบถามเพิ่มเติม
