CPU

800MHz

800MHz

1.3GHz

1.3GHz

Forwarding Performance In Service (IMIX)

200 Mbps

200 Mbps

800Mbps

800Mbps

Memory

1 GB

1 GB

1 GB

1 GB

Flash

(default/maximum)

256 MB

256 MB

256 MB/32GB

256 MB/32GB

External Flash

N/A

N/A

Micro SD card

Micro SD card

USB ports

N/A

1

1

1

CON ports

1

1

1

1

WAN ports

2 × GE copper ports

4 × GE copper ports

1 × GE copper ports

1 × GE combo port

3 × GE copper ports

1 × GE combo port

LAN ports

4 × GE ports (can be configured as WAN interfaces)

6 × GE ports (can be configured as WAN interfaces)

4 × GE ports(can be configured as WAN interfaces)

6 × GE ports (can be configured as WAN interfaces)

Console ports

1

1

1

1

Max power consumption

22 W

22 W

22 W

22 W

Rated voltage

100 VAC to 240 VAC @ 50 Hz/60 Hz

Dimensions (H × W × D)

44 × 440 × 225 mm (1.73 × 17.32 × 8.86 in)

Weight

2.45 kg (5.40 lb)

Operating temperature

0ºC to 45ºC (32°F to 113°F)

Operating humidity

5% RH to 95% RH, non-condensing

EMC

FCC Part 15 (CFR 47) CLASS A

ICES-003 CLASS A

VCCI-3 CLASS A

VCCI-4 CLASS A

CISPR 22 CLASS A

EN 55022 CLASS A

AS/NZS CISPR22 CLASS A

CISPR 24

EN 55024

EN 61000-3-2

EN 61000-3-3

EN 61000-6-1

ETSI EN 300 386

EN 301 489-1

EN 301 489-17

Security

UL 60950-1

CAN/CSA C22.2 No 60950-1

IEC 60950-1

EN 60950-1/A11

AS/NZS 60950

EN 60825-1

EN 60825-2

FDA 21 CFR Subchapter J

GB 4943

Layer 2 switching

Ethernet, Ethernet II, VLAN (port-based VLAN, guest VLAN), 802.3x, 802.1p, 802.1Q, 802.1X, STP (802.1D), RSTP (802.1w), MSTP (802.1s), PPP, PPPoE client, PPPoE server, and DDR

IP services

Unicast/multicast, TCP, UDP, IP option, IP unnumbered, policy-based routing, NetStream, and sFlow

IP application

Ping, Tracert, ICMP, DHCP server, DHCP relay, DHCP client, DNS client, DNS proxy, DDNS, NTP, and SNTP

IPv4 routing

Static routing

Dynamic routing: RIPv1/v2, OSPFv2, BGP, IS-IS

Route iteration

Policy routing

Equal-cost multi-path routing (ECMP)

Multicast routing: IGMPv1/v2/v3, PIM-DM, PIM-SM, MBGP, MSDP

IPv6

IPv6 ND, IPv6 PMTU, IPv6 FIB, IPv6 ACL, NAT-PT, 6PE, and DS-LITE

IPv6 tunneling: Manual tunneling, automatic tunneling, GRE tunnel, 6to4, ISATAP

Static routing

Dynamic routing: RIPng, OSPFv3, IS-ISv6, BGP4+

IPv6 multicast: MLDv1/v2, PIM-DM, PIM-SM

QoS

LR, port-based mirroring, Port Trust Mode, and port priority

Committed access rate (CAR)

FIFO, WFQ, CBQ

Generic Traffic Shaping (GTS)

Traffic classification

Security

PPPoE client & server, portal, 802.1X

Local authentication, RBAC, RADIUS, TACACS+

Basic Firewall Function, ASPF, ACL, filter, connection limit

IKE, IPsec

L2TP, NAT/NAPT, PKI, RSA, SSH v1.5/2.0, URPF, mGRE, GRE

ARP attack prevention

SSL VPN, ADVPN, GDVPN

AES, DES, 3DES,MD5, SHA1

MPLS

LDP, Static LSP

L3VPN: Inter-AS MPS VPN (Option 1/2/3), MPLS nested VPN, hierarchy of PE (HoPE), dual-homed CE, MCE, and multirole host

L2VPN: Martini, Kompella, CCC PWs and static PWs

MPLS TE, RSVP TE

High availability

VRRP, VRRPv3

Bandwidth-based load balancing and backup

IP address-based load balancing and backup

NQA collaboration with routing, VRRP or interface backup

Management and maintenance

SNMP v1/v2c/v3, MIB, SYSLOG, RMON

BiMS remote management, booting from USB drive

CLI, file system, and dual image

DHCP, FTP, HTTP, ICMP, UDP public, UDP private, TCP public, TCP private, and SNMP

Console port login, Telnet (VTY) login, SSH login, and FTP login
