Description
C1111-8P ISR 1100 8 Ports Dual GE WAN Ethernet Router
ขอใบเสนอราคา ขาย C1111-8P ISR 1100 8 Ports Dual GE WAN Ethernet Routers Discount ราคา ถูก โปรโมชั่นพิเศษ ได้ที่นี้
specification
Model | C1111-8P |
GE | 1 |
GE/SFP combo | 1 |
ADSL2/VDSL2+ | N/A |
LTE Advanced (CAT6) | N/A |
802.11ac | N/A |
GE | 8 |
PoE | 4 |
PoE+ | 2 |
Integrated USB 3.0 AUX/console | Yes |
Dimensions (H x W x D) | 1.75 x 12.7 x 9.03 in.
(42 x 323 x 230mm) (includes rubber feet) |
Weight with AC PS (w/o modules) | 5.5 Lbs. (2.5 kg) maximum |
Product Details
Figure 2 shows the back ports of C1111-8P. It doesn’t include the antennas.
Note:
① | LAN | ⑦ | GE 0/0/0 – SFP |
② | CLEI Label | ⑧ | GE 0/0/0 – RJ45 |
③ | Serial Number | ⑨ | GE 0/0/1 |
④ | Kensington Lock Slot | ⑩ | 4-pin Power Connector |
⑤ | RJ45 / Micro USB Console | ⑪ | Power Switch |
⑥ | USB3.0 | ⑫ | Reset Button |
Table 2 shows the business benefits.
Business need | Features/description |
Lightweight, compact size with low power consumption | ●Can be deployed in many different environments where space, heat dissipation, and low power consumption are critical factors. |
High performance to run concurrent services | ●High performance allows customers to take advantage of broadband network speeds while running secure, concurrent data, voice, video, and wireless services. |
High availability and business continuity | ● Redundant WAN connections for failover protection and load balancing.
● Dynamic failover protocols such as Virtual Router Redundancy Protocol (VRRP; RFC 2338), Hot Standby Router Protocol (HSRP), and Multigroup HSRP (MHSRP). |
Consistent, high application performance levels | ● The router can run multiple services simultaneously with minimal performance degradation. |
Risk mitigation with multilevel security | ● Network perimeter security with integrated application inspection firewall.
● Data privacy through high-speed IP Security (IPsec) Triple Data Encryption Standard (3DES), and Advanced Encryption Standard (AES) encryption. ● High-performance VPNs: DMVPN, FlexVPN, GET VPN, EzVPN ● Cisco Umbrella™ security architecture to provide content filtering via category-based URL classification and blocking, thus helping increase productivity and providing better use of company resources. ● Enforced security policy with OpenDNS. ● Security hardware acceleration. ● Trustworthy systems with Field-Programmable Gate Array (FPGA) and hardware anchor. ● Encrypted traffic analytics maintain integrity of encrypted flow |
Unified control of wired and wireless networks from a common console for streamlined operations | ● Simplifies and centralizes configuration and management of wireless and wireline devices. Supports WLAN services without requiring a wireless LAN controller.
● Supports Mobility Express for WLAN-enabled routers. |
Remote configuration and management to keep local IT staff lean | ● Supports separate console/auxiliary and USB ports.
● Can be configured to work with optional USB token. ● Supports TR-069. |
Performance
● Throughput ● Service reliability |
● Crypto performance up to 250 Mbps for 1100-8P and 150 Mbps for 1100-4P.
● A distributed multicore architecture with the industry’s first internal services plane. ● Remote installation of application-aware services that run identically to their counterparts in dedicated appliances. |
Lower WAN expenditures | ● Cisco Software-Defined WAN (SD-WAN) (over the Cisco Application Policy Infrastructure Controller Enterprise Module [APIC-EM]) support for optimized WAN connection. |
Pay as you grow: IPsec performance upgrade model | ● Router IPsec capacity can be increased with a remote performance-on-demand license upgrade (no hardware upgrade) for exceptional savings andCapEx budget management. |
IT consolidation, space savings, and improved Total Cost of Ownership (TCO) | ● Single converged branch platform integrates routing, switching, security, and performance management capabilities. |
Business continuity and increased resiliency | ● The entire 1100 Series supports Power over Ethernet (PoE) and PoE+ power to endpoints. |
Product Accessories
Licenses
Table 3 shows the licenses for C1111-8P.
Licenses | Description |
C1-SL-1100-8P-APP | AppX Foundation License for Cisco ISR 1100 8P Series |
SL-1100-8P-SEC | Security License for Cisco ISR 1100 8P Series |
SL-1100-8P-SECNPE | NPE Security License for Cisco ISR 1100 8P Series |
C1-SL-1100-8P-SEC | Security Foundation License for Cisco ISR 1100 8P Series |
FL-VPERF-8P-200 | IPSEC PLUS 200 Mbps License for Cisco ISR 1100 8P Series |
Small Form-Factor Pluggable Supported
Table 4 shows the SFP for Cisco 1100 Series Routers.
Small Form-Factor Pluggable | ISR 1100 8P | ISR 1100 4P | Description |
GLC-EX-SMD | Yes | Yes | 1000BASE-EX SFP transceiver module, SMF, 1310nm, DOM. |
GLC-LH-SMD | Yes | Yes | GE SFP, LC connector LX/LH transceiver; with DOM. |
GLC-SX-MMD | Yes | Yes | GE SFP, LC connector SX transceiver; with DOM. |
GLC-ZX-SMD | Yes | Yes | 1000BASE-ZX SFP; with DOM. |
GLC-FE-100ZX | Yes | Yes | 100BASE-ZX SFP (80km). |
GLC-GE-100FX | Yes | Yes | 100FX SFP on GE ports. |
GLC-BX-D | Yes | Yes | 1000BASE-BX SFP, 1490NM. |
GLC-BX-U | Yes | Yes | 1000BASE-BX SFP, 1310NM. |
Compare to Similar Item
Table 5 shows the comparison between C1111-4P and C1111-8P.
Model | C1111-8P | C1111-4P |
WAN GE | 1 | 1 |
WAN GE/SFP combo | 1 | 1 |
ADSL2/VDSL2+ | N/A | N/A |
LTE Advanced (CAT6) | N/A | N/A |
802.11ac | N/A | N/A |
LAN GE | 8 | 4 |
PoE | 4 | 2 |
PoE+ | 2 | 1 |
Integrated USB 3.0 AUX/console | Yes | Yes |
Warranty
Warranty / เงื่อนไขการรับประกัน: ติดต่อสอบถามเพิ่มเติม
Remark
1. รูปสินค้าที่แสดงเป็นเพียงรูปภาพประกอบการขายเท่านั้น
2. ทางบริษัทฯ ขอสงวนสิทธิ์ในการเปลี่ยนแปลงราคาและโปรโมชั่นโดยไม่แจ้งให้ทราบล่วงหน้า
3. ทางบริษัทฯ ขอสงวนสิทธิ์ในการรับผิดชอบใดๆ อันเนื่องจากข้อผิดพลาดจากการนำข้อมูลเข้าสู่หน้า Website เช่น รุ่นสินค้า, รายละเอียดสินค้า, รูปภาพสินค้า เป็นต้น
