Description
ขอใบเสนอราคา ขาย Tp-Link DS-LGPA-08 8-port OLT GPON Service Board ราคา Discount ราคา ถูก โปรโมชั่นพิเศษ ได้ที่นี้
specification
DS-LGPA-088-port OLT GPON Service Board
SPEC: 8x SFP GPON ports
FEATURE: Service Board for DS-P8000-X2 and DS-P8000-X7
DS-LGPA-08
DeltaStream Chassis Optical Line Terminal 8 GPON Service Board
- 8× GPON Ports: Delivers high-speed transition rate up to 2.488 Gbps downstream and 1.244 Gbps upstream (per port).
- High Scalability: Supports 1:128 splitting ratio for GPON services (per port).
- Flexible Deployment: Comaptible with TP-Link’s Chassis optical line terminals and supports hot swapping for seamless upgrading.
- L2 & Advanced L3 Functions: Rich and robust functions satisfy flexible deployment and scalability needs.
- Centralized Management: Supports the management via the DeltaStream PON Management System (DPMS), SNMP, CLI, and Web UI.
HARDWARE FEATURES | |
---|---|
Interface | 8× GPON Ports |
Power Supply | Power Supplies: via DS-PSUA Module DC: -38.4V~-57.6V |
Power Consumption | Max. 30W |
Hot Swappable | Yes |
Dimensions ( W x D x H ) | 15.4 x 10.1 x 0.9 in (390.8mm x 257.5mm x 22.5 mm) |
SOFTWARE FEATURES | |
---|---|
Security | ACL 802.1x Authentication |
DHCP | DHCP Server DHCP Relay |
OMCI | Standard OMCI Management Supported |
ONU Authentication | ONU Auto Authentication |
ONU Security | Rouge ONU Detection and Isolation |
Multi-Service | Multi-Service Traffic Identify and Rate Limit |
QoS | IEEE 802.1p/DSCP QoS Voice VLAN Auto VoIP |
Routing | Static Routing |
Mulitcast | IGMP Snooping MLD Snooping |
Centralized Management | Large-Scale Devices Management OLT Batch Configure, Upgrade, Reboot Multi-Site Management Intelligent Network Monitoring Real-time Network Overview |
GPON PORT ATTRIBUTE | |
---|---|
Max. Splitting Ratio | 1:128 for GPON |
Transmission distance | 20 km |
Data rate | GPON Downstream: 2.5 Gbps, Upstream: 1.25 Gbps *Per Port |
Wavelength | Tx: 1490 nm Rx: 1310 nm |
OTHERS | |
---|---|
Certification | CE, FCC |
Package Contents | GPON Service Board DS-LGPA-08 |
Environment | Operating Temperature: 0℃–50℃ (32℉–122℉) Storage Temperature: -40℃–70℃ (-40℉–158℉) Operating Humidity: 10%–90% non-condensing Storage Humidity: 5%–90% non-condensing |
