Specification

Prodouct : F1109P-8-102W

Brand : IP-COM

รองรับ IEEE802.3af/at

รองรับ IEEE802.3af/at

– (9) 10/100Mbps Base-T RJ45 Ports

– 2K MAC address

– Power Budget 120W

– Supports port VLAN; ports 1 to 8 can communicate

  with the uplink port (port 9) but cannot communicate with each other

– 2K MAC address and MAC address learning

– 1.8 Gbps switching fabric for non-blocking line-speed forwarding

Interface : 8 10/100M Base-T ports(Data/Power), 1 10/100M Base-T ports(Data)

Port Lightning Protection : 6KV

Store and forward : Yes

Exchange Capacity : 1.8 Gbps

Packet forwarding rate : 1.34Mpps

MAC Address Table : 2K

PoE supply management : Port 1-8 support IEEE802.3at/af PoE standard

PoE through pin : 1 2 4 5 +;3 6 7 8 –

Voltage input range  : AC: 100-240V～50/60Hz

DC  : 51V 2A

Dimensions ( W x D x H )  : 177.5x104x26mm

Waranty : 3 year warranty
