Description
ขอใบเสนอราคา ขาย SRTG10KRMXLI APC Smart-UPS SRTG 10000VA ราคา Discount ราคา ถูก โปรโมชั่นพิเศษ ได้ที่นี้
specification
SRTG10KRMXLI APC SRTG10KRMXLI Kit APC Smart-UPS SRTG 10000VA 230V 5 X 8 Power Up for (1) Smart-UPS Preventive Maintenance 5×8 Smart-UPS x 6 units NBD On-Site Upgrade Warranty Smart-UPS x 3 units APC SMART-UPS RT 19″ Rail Kit For 5k/6k/8k/10k/15k/20kVA
Main Input Voltage | 230 V 400 V 3 phases |
---|---|
Other Input Voltage | 220 V 240 V 380 V 415 V |
Main Output Voltage | 230 V |
Other Output Voltage | 220 V 240 V |
rated power in W | 10000 W |
rated power in VA | 10000 VA |
nb of power socket outlets | 6 IEC 60320 C13 3 IEC Jumpers 4 IEC 60320 C19 |
output connector type | Hard wire 3-wire (H N + E) 1 |
number of rack unit | 6U |
battery type | Lead-acid battery |
provided equipment | CD with software Documentation CD Installation guide Rack mounting hardware Rack mounting brackets Rack mounting support rails Temperature probe USB cable Warranty card Web/SNMP management card |
product web sub-family | High density |
---|---|
Number of power module free slots | 0 |
Number of power module filled slots | 0 |
redundant | No |
colour | Black |
---|---|
height | 26.3 cm |
width | 43.2 cm |
depth | 71.5 cm |
net weight | 111.82 kg |
mounting location | Front |
mounting preference | No preference |
mounting mode | Rack-mounted |
two post mountable | 0 |
USB compatible | Yes |
network frequency | 40…70 Hz auto-sensing |
---|---|
number of input connectors | 1 hard wire 3-wire (1P + N + E) 1 hard wire 5-wire (3P + N + E) |
input voltage limits | 100…275 V adjustable (half load) 173…476 V adjustable (half load) |
Maximum configurable power in W | 10000 W |
---|---|
harmonic distortion | Less than 2 % |
output frequency | 50/60 Hz +/- 3 Hz sync to mains |
crest factor | 3 : 1 |
UPS type | Double conversion online |
Wave type | Sine wave |
bypass type | Internal bypass (automatic and manual) |
Maximum configurable power in VA | 10000 VA |
product certifications | CE EAC IRAM RCM VDE |
---|---|
marking | CE Mark |
standards | EN/IEC 62040-1 EN/IEC 62040-2 |
ambient air temperature for operation | 0…40 °C |
---|---|
relative humidity | 0…95 % non-condensing |
operating altitude | 0…10000 ft |
ambient air temperature for storage | -15…45 °C |
storage Relative Humidity | 0…95 % Non-condensing |
storage altitude | 0.00…15240.00 m |
acoustic level | 55 dBA |
heat dissipation | 1947 Btu/h |
IP degree of protection | IP20 |
