Description
ขอใบเสนอราคา ขาย TR-1000 CLEANLINE Pf 0.9 True On-Line Double Conversion Discount โปรโมชั่น ราคา ถูก โปรโมชั่นพิเศษ ได้ที่นี้
specification
- เป็น UPS ชนิด True On-line Double Conversion ให้กระแสไฟฟ้าที่คงที่และต่อเนื่องตลอดเวลา
- ไมโครโปรเซสเซอร์ควบคุมการทำงานทั้งหมด เพื่อความเที่ยงตรงของไฟฟ้าขาออก
- แรงดันไฟฟ้าขาเข้า 220 Vac +/- 25% (Full load)
- แรงดันไฟฟ้าขาออก 220, 230 & 240 Vac +/- 1% (สามารถเลือกแรงดันไฟขาออกได้)
- สัญญาณไฟฟ้าขาออกของภาค Inverter เป็น Pure Sine Wave
- สำรองไฟฟ้าได้ประมาณ 10-30 นาที (ขึ้นอยู่กับอุปกรณ์)
- สามารถเพิ่มระยะเวลาการสำรองไฟฟ้าด้วยการพ่วงแบตเตอรี่ได้ (Options)
- สามารถชาร์จแบตเตอรี่ได้โดยไม่จำเป็นต้องเปิดเครื่อง และสามารถเปิดเครื่องได้โดยไม่ต้องมีไฟ AC INPUT (DC Power On)
- มีสัญญาณไฟ LCD เตือนบอกสภาวะการทำงาน : UPS On, On-line, battery mode, bypass mode & alarm
- มีสวิตฉุกเฉินสำหรับปิดการทำงานของเครื่องสำรองไฟฟ้า (Emergency power off)
- สามารถควบคุมการเปิดปิดปลั๊กไฟขาออกเป็นชุดๆ ได้เพื่อประโยชน์ในการเพิ่มระยะเวลาสำรองไฟฟ้า
- สามารถเลือกให้เครื่องสำรองไฟฟ้าทำงานในโหมดประหยัดพลังงานได้ (High efficiency mode)
- รองรับการใช้งานผ่านพอร์ตสัญญาณ RS232, USB PORT สำหรับเชื่อมต่อกับคอมพิวเตอร์ผ่านโปรแกรม ViewPower สำหรับตรวจสอบและควบคุมการทำงานของเครื่องสำรองไฟฟ้า (UPS)
- รองรับการใช้งานร่วมกับ SNMP Card เพื่อความสะดวกในการควบคุมการทำงานของ UPS ผ่านระบบ Network
- ผลิตภัณฑ์มาตรฐาน ISO 9001, ISO 14001 และ มอก. 1291 เล่ม 1-2553, มอก. 1291 เล่ม 2-2553, มอก. 1291 เล่ม 3-2555
TECHNICAL SPECIFICATION | |
Rack-mount Model | TR-1000 |
Power Rating | 1kVA/900W |
Input | |
Voltage | 110-300Vac at 50%load, 160-300Vac at 100% load |
Frequency | 50 or 60Hz ± 10% |
Phase | Single phase with ground |
Power factor | >0.99 @ nominal voltage (100% Load) |
Output | |
Voltage | 208/220/230/240Vac |
Voltage regulation | ±1% |
Frequency | 50 or 60Hz ±0.1% (Battery mode) |
Overload recovery | Auto transfer to UPS |
UPS Design technology | True on-line double conversion, Full digitized microprocessor controlled |
Crest factor | 3:1 |
Harmonic distortion | ≤2% THD (Linear load), ≤4% THD (Non-Linear load) |
Output waveform | Pure sinewave |
Transfer time | 0 ms |
Efficiency | |
AC mode | >90% |
Battery mode | >89% |
ECO mode | >97% |
Protection and Filtering | |
Surge protection | IEC61000-4-5 Class 3 |
Overload protection | UPS Automatic bypass if overload between 110% to 130% at 30 seconds and more than 130% at 1.5 seconds |
Short circuit protection | UPS Output cut off immediately or input fuse/circuit breaker protection |
Battery | |
Type | Sealed, Maintenance-free lead acid batteries |
Typical recharge time to 90% | 4 hours |
Management | Self-test |
Battery protection | Cut off without draining any current when battery is low |
Cold start (DC start) | Yes |
Back up time | 15-30 minutes (Depending on computer load) |
Expansion back up time | Depending on customer required |
Indicators | |
Status | UPS status, Load level, Battery level, Input/output voltage, Remaining backup time, and Fault conditions |
Audible Alarm | |
Battery mode | Sounding every 4 seconds |
Low battery | Sounding every second |
Overload | Sounding twice every second |
Fault | Continuously sounding |
Dimension (DxWxH mm) | 480 x 438 x 88 (2U) |
Weight (kg) | 18.4 |
Environmental | |
Operating temperature | 0-40 °c |
Relative humidity | 0-95% (Non-Condensing) |
Noise level | <45dB@1 Meter |
Interface | |
Smart RS232 | Software supports windows family, Linux, Sun solarris, IBM aix, Compaq true64, SGI IRIX, FreeBSD, HP-UX and MAC |
USB | Windows family and MAC OS |
SNMP(Option) | Power management from SNMP manager and web browser |
Authorized Distributor | All brands and logos are registered trademarks of their respective owners. Specifications are subject to change without notice. |
